Bridge Pile and Truss Repair

For this bridge and pile repair project, HJ3 repaired and strengthened a bridge that had 93 concrete piles and 2 reinforced trusses in need of repair and strengthening. HJ3’s patented products were used to repair and strengthen the piles 10 feet above and 5 feet below the waterline.
Watch the video on our Facebook site

bridge with many concrete piles needing repair   2
For this project, HJ3 had an above-water and below-water team of certified installers. The degraded concrete was removed and the piles and trusses cleaned.

5   Bridge with many piles over water

The bridge was repaired and strengthened above and below the water, then wrapped with HJ3’s carbon fiber and CFRP. The piles above water had a UV and pH protective coating applied over the carbon fiber.

DESIGN: HJ3 relies on ACI-440.2R-08 ” Guide for the Design & Construction of Externally Bonded FRP Systems for Strengthening Concrete Structures

STRENGTH: HJ3 verified the strength of its underwater system in accordance with ASTM D3039.

HJ3’s team of engineers will design custom structural solutions for you.
Call us today! 877-303-0453 or email us at: info@hj3.com
To find out more about this project, watch the video…
